AWS VPC Networking: Subnets, NAT Gateways & Security Groups Explained
•12 min read•Subid Das
awsnetworkingdevopsvpccloud-infrastructure
VPC is AWS's networking layer. Misunderstand it, and your infrastructure is either insecure or unreachable. This guide covers production-grade VPC design.
VPC Fundamentals#
A VPC is an isolated network within AWS. You define IP address ranges, subnets, routing, and security.
VPC (10.0.0.0/16)
├── Public Subnet (10.0.1.0/24) - EC2, ALB
│ └── Internet Gateway → Internet
├── Private Subnet (10.0.2.0/24) - RDS, ElastiCache
│ └── NAT Gateway → Internet (one-way)
└── Database Subnet (10.0.3.0/24) - RDS cluster
Step 1: Create VPC & Subnets#
# main.tf - VPC and subnets
resource "aws_vpc" "main" {
cidr_block = "10.0.0.0/16"
enable_dns_hostnames = true
enable_dns_support = true
tags = { Name = "main-vpc" }
}
# Public Subnet (AZ-a)
resource "aws_subnet" "public_a" {
vpc_id = aws_vpc.main.id
cidr_block = "10.0.1.0/24"
availability_zone = "us-east-1a"
map_public_ip_on_launch = true # Auto-assign public IPs
tags = { Name = "public-subnet-a" }
}
# Public Subnet (AZ-b) - High Availability
resource "aws_subnet" "public_b" {
vpc_id = aws_vpc.main.id
cidr_block = "10.0.2.0/24"
availability_zone = "us-east-1b"
map_public_ip_on_launch = true
tags = { Name = "public-subnet-b" }
}
# Private Subnet (AZ-a)
resource "aws_subnet" "private_a" {
vpc_id = aws_vpc.main.id
cidr_block = "10.0.11.0/24"
availability_zone = "us-east-1a"
tags = { Name = "private-subnet-a" }
}
# Private Subnet (AZ-b)
resource "aws_subnet" "private_b" {
vpc_id = aws_vpc.main.id
cidr_block = "10.0.12.0/24"
availability_zone = "us-east-1b"
tags = { Name = "private-subnet-b" }
}
Subnet CIDR breakdown:
- VPC: 10.0.0.0/16 = 65,536 IPs
- Public-a: 10.0.1.0/24 = 256 IPs (250 usable)
- Public-b: 10.0.2.0/24 = 256 IPs
- Private-a: 10.0.11.0/24 = 256 IPs
- Private-b: 10.0.12.0/24 = 256 IPs
Step 2: Internet Gateway (Public Access)#
# Internet Gateway - allows public traffic
resource "aws_internet_gateway" "main" {
vpc_id = aws_vpc.main.id
tags = { Name = "main-igw" }
}
# Public Route Table - route to IGW
resource "aws_route_table" "public" {
vpc_id = aws_vpc.main.id
route {
cidr_block = "0.0.0.0/0" # All traffic
gateway_id = aws_internet_gateway.main.id
}
tags = { Name = "public-rt" }
}
# Associate public subnets with public route table
resource "aws_route_table_association" "public_a" {
subnet_id = aws_subnet.public_a.id
route_table_id = aws_route_table.public.id
}
resource "aws_route_table_association" "public_b" {
subnet_id = aws_subnet.public_b.id
route_table_id = aws_route_table.public.id
}
Now public subnets can reach the internet:
Public EC2 → Internet Gateway → AWS edge → Internet (0.0.0.0/0)
Step 3: NAT Gateway (Private Internet Access)#
Private instances can't reach internet directly. NAT Gateway provides one-way outbound access.
# Elastic IP for NAT Gateway
resource "aws_eip" "nat_a" {
domain = "vpc"
depends_on = [aws_internet_gateway.main]
tags = { Name = "nat-eip-a" }
}
# NAT Gateway (in public subnet!)
resource "aws_nat_gateway" "nat_a" {
allocation_id = aws_eip.nat_a.id
subnet_id = aws_subnet.public_a.id # Must be public
depends_on = [aws_internet_gateway.main]
tags = { Name = "nat-gw-a" }
}
# Private Route Table
resource "aws_route_table" "private_a" {
vpc_id = aws_vpc.main.id
route {
cidr_block = "0.0.0.0/0"
nat_gateway_id = aws_nat_gateway.nat_a.id
}
tags = { Name = "private-rt-a" }
}
# Associate private subnets
resource "aws_route_table_association" "private_a" {
subnet_id = aws_subnet.private_a.id
route_table_id = aws_route_table.private_a.id
}
Important: Create one NAT per AZ for redundancy:
# NAT in AZ-b
resource "aws_eip" "nat_b" {
domain = "vpc"
}
resource "aws_nat_gateway" "nat_b" {
allocation_id = aws_eip.nat_b.id
subnet_id = aws_subnet.public_b.id
}
resource "aws_route_table" "private_b" {
vpc_id = aws_vpc.main.id
route {
cidr_block = "0.0.0.0/0"
nat_gateway_id = aws_nat_gateway.nat_b.id
}
}
resource "aws_route_table_association" "private_b" {
subnet_id = aws_subnet.private_b.id
route_table_id = aws_route_table.private_b.id
}
Now private instances can download updates:
Private EC2 → NAT Gateway (in public subnet) → Internet Gateway → Internet
Incoming traffic → DROPPED (NAT is one-way)
Step 4: Security Groups (Firewalls)#
Security groups control inbound/outbound traffic.
# ALB Security Group
resource "aws_security_group" "alb" {
name = "alb-sg"
vpc_id = aws_vpc.main.id
ingress {
from_port = 80
to_port = 80
protocol = "tcp"
cidr_blocks = ["0.0.0.0/0"] # Allow HTTP from anywhere
}
ingress {
from_port = 443
to_port = 443
protocol = "tcp"
cidr_blocks = ["0.0.0.0/0"] # Allow HTTPS from anywhere
}
egress {
from_port = 0
to_port = 0
protocol = "-1"
cidr_blocks = ["0.0.0.0/0"] # Allow all outbound
}
tags = { Name = "alb-sg" }
}
# Application Security Group
resource "aws_security_group" "app" {
name = "app-sg"
vpc_id = aws_vpc.main.id
# ALB → App servers
ingress {
from_port = 3000
to_port = 3000
protocol = "tcp"
security_groups = [aws_security_group.alb.id] # Only from ALB
}
egress {
from_port = 0
to_port = 0
protocol = "-1"
cidr_blocks = ["0.0.0.0/0"]
}
tags = { Name = "app-sg" }
}
# Database Security Group
resource "aws_security_group" "rds" {
name = "rds-sg"
vpc_id = aws_vpc.main.id
# App servers → RDS
ingress {
from_port = 5432
to_port = 5432
protocol = "tcp"
security_groups = [aws_security_group.app.id] # Only from app
}
egress {
from_port = 0
to_port = 0
protocol = "-1"
cidr_blocks = ["0.0.0.0/0"]
}
tags = { Name = "rds-sg" }
}
Traffic flow:
Internet → ALB (80/443) → App SG (3000) → RDS SG (5432) → Database
Each layer accepts traffic only from the previous layer. Defense in depth.
Network Architecture Diagram#
┌─────────────────────── VPC: 10.0.0.0/16 ──────────────────────┐
│ │
│ ┌──────────────────── Public Subnets ──────────────────────┐ │
│ │ │ │
│ │ 10.0.1.0/24 (AZ-a) 10.0.2.0/24 (AZ-b) │ │
│ │ ┌──────────────────────┐ ┌──────────────────────┐ │ │
│ │ │ ALB │ │ ALB │ │ │
│ │ │ 10.0.1.10 │ │ 10.0.2.10 │ │ │
│ │ │ alb-sg │ │ alb-sg │ │ │
│ │ └──────────────────────┘ └──────────────────────┘ │ │
│ │ ↓ ↓ │ │
│ │ ┌──────────────────────┐ ┌──────────────────────┐ │ │
│ │ │ NAT Gateway │ │ NAT Gateway │ │ │
│ │ │ 10.0.1.5 │ │ 10.0.2.5 │ │ │
│ │ │ EIP: 54.1.1.1 │ │ EIP: 54.1.1.2 │ │ │
│ │ └──────────────────────┘ └──────────────────────┘ │ │
│ │ │ │
│ └───────────────────────────────────────────────────────────┘ │
│ ↓ Internet Gateway (IGW) ↓ │
│ ┌──────────────────── Private Subnets ─────────────────────┐ │
│ │ │ │
│ │ 10.0.11.0/24 (AZ-a) 10.0.12.0/24 (AZ-b) │ │
│ │ ┌──────────────────────┐ ┌──────────────────────┐ │ │
│ │ │ App Server 1 │ │ App Server 2 │ │ │
│ │ │ 10.0.11.10 │ │ 10.0.12.10 │ │ │
│ │ │ app-sg │ │ app-sg │ │ │
│ │ └──────────────────────┘ └──────────────────────┘ │ │
│ │ ↓ ↓ │ │
│ │ ┌──────────────────────┐ ┌──────────────────────┐ │ │
│ │ │ RDS Primary │ │ RDS Standby │ │ │
│ │ │ 10.0.11.50 │ │ 10.0.12.50 │ │ │
│ │ │ rds-sg │ │ rds-sg │ │ │
│ │ └──────────────────────┘ └──────────────────────┘ │ │
│ │ │ │
│ └───────────────────────────────────────────────────────────┘ │
│ │
└─────────────────────────────────────────────────────────────────┘
↓
Internet
VPC Flow Logs (Troubleshooting)#
# Enable VPC flow logs to CloudWatch
resource "aws_flow_log" "main" {
iam_role_arn = aws_iam_role.flow_logs.arn
log_destination = aws_cloudwatch_log_group.flow_logs.arn
traffic_type = "ALL" # ALL, ACCEPT, REJECT
vpc_id = aws_vpc.main.id
tags = { Name = "vpc-flow-logs" }
}
resource "aws_cloudwatch_log_group" "flow_logs" {
name = "/aws/vpc/flow-logs"
retention_in_days = 7
}
Query logs to debug connectivity:
-- Find rejected traffic
fields srcaddr, dstaddr, dstport, action
| filter action = "REJECT"
| stats count() by dstport
Best Practices#
| ✅ Do | ❌ Don't |
|---|---|
| Multi-AZ subnets | Single AZ (single point of failure) |
| One NAT per AZ | One NAT for all (bottleneck) |
| Security groups as firewall | Open all ports (0.0.0.0/0) |
| Small CIDR blocks | Over-sized (hard to expand) |
| VPC Flow Logs | No logging (debug nightmares) |
| Private RDS | Public RDS (security risk) |
Checklist#
- VPC CIDR block (e.g., 10.0.0.0/16)
- Public subnets in 2+ AZs
- Private subnets in 2+ AZs
- Internet Gateway for public traffic
- NAT Gateways (one per AZ)
- Route tables for public/private
- Security groups for each tier
- VPC Flow Logs enabled
- NACLs configured (if needed)
- VPC Endpoints for AWS services (optional, advanced)
Conclusion#
VPC design is foundational. Get it right once, scale to thousands of instances. Get it wrong, and you'll rewrite it later.
Use multi-AZ design from day one. Security groups are cheap. NAT Gateways cost ~$30/month—well worth the isolation.
Auditing an AWS environment that's outgrown its original VPC design? Book a 15-minute call.
FAQ
Do I need a NAT Gateway for every private subnet?
One NAT Gateway per AZ, shared across that AZ's private subnets, is the standard pattern — one per subnet is unnecessary cost, one for the whole VPC is a single point of failure across AZs.
What's the real cost of a NAT Gateway?
Roughly $30-35/month plus data processing charges per gateway — cheap relative to the isolation and multi-AZ resilience it buys.
Can I fix VPC design after launch, or does it need to be right from day one?
It can be fixed later, but rarely without downtime — re-architecting CIDR ranges, subnet layout, or routing tables under live traffic is riskier than getting the design right before the first instance launches.
